Scope of application
CJ20 series AC contactor (hereinafter referred to as the contactor), is mainly used in the circuit of AC 50Hz (or 60Hz), rated working voltage up to 660V, rated current up to 630A, for remote switch on and off the circuit, and can combine with the appropriate thermal overload relay, to protect the circuit which may operate over the load.
The contactor conforms to the IEC60947-4-1 and GB14048.4 standards.
Ordering instructions
The following must be pointed out when an order is placed: Product model name, coil operating voltage and frequency
For example: CJ20-25A 380V 50Hz 50 units;
